Carbon Mesh

Carbonfib Carbon Mesh is an extremely strong reinforcement material which designed for structural reinforcement applications. It's designed for FRCM applications.

One- or two-way carbon fibers.
High tensile strength.
High ductility.
High durability properties.
It is suitable for new generation FRCM applications.
It is suitable for using together with cementitious mortars.
Thanks to its natural structure, it is long-lasting.
With special coating, it has high adherance with cementitious matrix.
It greatly improves the seismic performance of the reinforced and masonary structures.
Different weight and mesh openning options.
It has been specially developed for reinforcement applications and is manufactured from high quality carbon fibers.

Product	Unit Weight (g/m²)	Apperture Size ( mm)	Strength (MPa)
CM100	100	25 x 25	4200
CM200	200	25 x 25	4200
CM400	400	25 x 25	4200

* Listed items are standart products. The carbon meshes can be procuded between 100-1200 g/m2

Carbonfib Carbon Mesh is chemical and corrosion resistant. Carbon Mesh is developed for FRCM and CRM application. It can be used structural cementituos mortars.

Thanks to its special polymeric coating, it shows high adhesion with commercially available cementitious mortars.
Suitable for retrofitting of masonary and reinforced concrete strcutures.
No maintenance required
Alkali resistant
Improving service life and durability
Thermal compatibility
Excellent fatigue behavior
Repairing or preventing seismic damage.
Replacing damaged or missing reinforcing steel
Extremely durable
Extremely resistant to a wide range of environmental conditions
Easy installation

Carbonfib Carbon Mesh is used to increase the load bearing capacity of the structure.

Columns strengthening
Beams strengthening
Slabs strengthening
Masonary walls strengthening

Product Range: 50 – 800 g/m²

Roll width: 100 cm

Roll length: 50m

Product	Unit Weight (g/m²)	Apperture Size (mm)	Crossection Area (mm²)	Strength (MPa)
CM100	100	25 x 25	28	4200
CM200	200	25 x 25	56	4200
CM400	400	25 x 25	112	4200
